DF-360 CRANE
Features & Specifications
- Hot-dipped galvanized.
- Stainless steel hardware.
- 360° swivel.
- 3 position adjustable length boom.
- Bearing is 7″ above deck.
MODEL NO.
DF-360
PART NO.
36000
CAPACITY
2,750 LBS
WEIGHT
2,156 LBS
DF-360 BARGE CRANE DIMENSIONS
MODEL NO.
DF-360 (1st Position)
DF-360 (2nd Position)
DF-360 (3rd Position)
A
12′ – 9″
15′ – 0″
17′ – 3″
B
6′ – 5″
6′ – 5″
6′ – 5″
C
7°
7°
7°
ØD
2′ – 2″
2′ – 2″
2′ – 2″
E
3°
3°
3°
