| MODEL No. | PART No. | SIZE | A | B | ØC | D | E | F | G | ØH | I | WT. (lbs) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| DF-537 | 89648 | 10" | 45" | 15" | 9" | 1 1/2" | 27" | 4 1/2" | 18" | 13 1/2" | 2 1/2" | 625 |
| DF-537A | 90034 | 10" W/HORNS | 45" | 15" | 9" | 1 1/2" | 27" | 4 1/2" | 18" | 13 1/2" | 2 1/2" | 635 |
| DF-537AA | 90036 | 10" W/HORNS | 45" | 15" | 9" | 1 1/2" | 27" | 4 1/2" | 18" | 13 1/2" | 2 1/2" | 645 |
| NOTES: 1. OPTIONAL HORNS NOT SHOWN ON DOUBLE BITT MODEL. |
||||||||||||
