NABRICO - DFSK-48TDKC Cast Steel Thru Deck Raised Kevel
Steel Kevel Chock
Cast Steel
Cast Steel Heavy
Thru Deck
Cast Steel Raised
MODEL No.
PART No.
SIZE
A
B
C
D
E
F
G
H
I
J
ØK
WT. (lbs)
DFSK-48TDKC
90027
48"
24"
18"
48"
12"
9"
6"
7/8"
15"
3/8"
8"
6"
300
MODEL No.
PART No.
SIZE
A
B
C
D
E
F
G
H
I
J
ØK
WT. (kg)
DFSK-48TDKC
90027
1219 mm
610 mm
457 mm
1219 mm
305 mm
229 mm
152 mm
22 mm
381 mm
10 mm
203 mm
152 mm
137
