DF-1 Electric Winch

NABRICO DF-1 ElectricWinch
NABRICO DF-1 ElectricWinch
Features
  • Salt water package standard on all power winches.
  • Hot-dipped galvanized.
  • Stainless or silicon bronze fasteners.
  • 3-ply conveyer belt covers (damage and corrosion-resistant).
  • 3-tooth locking dog with large release and fail-safe disc brake.
  • Provisions for emergency manual operation with cordless drill.
  • NEMA motor design with cycloidal gearbox.
  • Control box option: NEMA 4X stainless steel.
  • Minimal maintenance and easy to repair.
  • Variable frequency drive option available. Amp draw limits, variable speeds, and motor protection.
  • Made as one model adjustable to true right or left hand models for use in pairs.
  • Over 100 fewer parts than other electric winches (no chain or sprockets).
  • Heaviest winch in its class.
  • 30 Ton - 5 HP motor standard.
  • 40 Ton - 7.5 HP motor standard.
  • 50 Ton - 10 HP motor standard.
  • 65 Ton - 10 HP motor standard.
  • Other line pulls and speeds available.
